UT Standard UV Marking Machine
UV laser marking machine is mainly suitable for surface and internal engraving of glass and crystal products, such as mobile phone screens, LCD screens, optical devices, automotive glass, etc. At the same time, it can be applied to the surface processing of most metal and non-metal materials and the processing of coating film. Such as hardware, ceramics, glasses and clocks, PC, electronic devices, various instruments, PCB boards and control panels, nameplate display boards, plastics, etc., suitable for surface treatment such as marking and engraving of high flame retardant materials.
content Us:+86 15253660692
Product Description
| Main Parameter | |
| Series | UT standard UV marking machine |
| Laser power | 3W 5W |
| Laser wavelength | 355nm |
| Mark depth | 0-3mm (depending on material) |
| Line width | 0.02mm |
| Minimum character | 0.1mm |
| Max marking speed | 7000mm/s |
| positioning accuracy | ±0.05 |
| Marking range | 100*100mm 130*130mm 160*160mmm (customizable) |
| Cooling method | Water-cooling |
| Power Specifications | 220V/50Hz |
| Equipment size | 920*760*1100mm |
| Weight | 100kg |
| 1. Laser: The laser can choose Raycus, Maxphotonics, JPT, etc., with stable laser output and long service life; | |
| 2.Galvanometer: The galvanometer adopts Jinhaichuang or wavelength high-speed scanning galvanometer system, which is suitable for large-scale processing needs, with fast processing speed and good effect; | |
| 3.Lens: It adopts imported photosensitive field lens, which is small in size and suitable for harsh environments. It improves the ability of the edge beam to enter the detector, so that the non-uniform illumination on the photosensitive surface of the detector can be homogenized; | |
| 4.Control board: mainly used in galvanometer laser marking machine hardware with fast data processing speed, high precision and high-speed and high-precision non-standard functions. | |
